Aluminium cladding architectural case studies to spark your creativity and inspire your next project.
| Cladding Material | Material Cost (per sq ft) | Total Installed Cost (per sq ft) | Lifespan | Weather Resistance | Installation Difficulty |
| Aluminum Cladding (XtraMetal) | $8 – $25 | $15 – $40 | 40 – 50+ Years | Excellent. Will not rust or corrode. Highly resistant to moisture, UV rays, and temperature changes. PVDF coating ensures color retention for 20+ years. Not ideal for high-impact zones (can dent). | Low to Medium. Lightweight panels and systemized installation (like Click-System) significantly reduce labor time and complexity. Does not require specialized heavy machinery. |
| Wood Cladding | $5 – $15 | $10 – $30 | 15 – 30 Years (with high maintenance) | Poor to Medium. Susceptible to rot, pests (termites), and moisture damage. Requires regular sealing, staining, or painting to maintain appearance and durability. Poor fire resistance unless specially treated. | Medium. Requires skilled carpentry for precise cutting and fitting. Material weight is moderate. Proper sealing and finishing are critical and time-consuming. |
| Vinyl Siding (PVC) | $2 – $7 | $4 – $12 | 20 – 40 Years | Medium. Waterproof, but can become brittle and crack in extreme cold or from physical impact. Colors can fade over time due to UV exposure. Can warp in high heat. | Low. Very lightweight and easy to cut and install. A popular choice for DIY projects. However, achieving a professional, seamless look can be challenging. |
| Fiber Cement | $4 – $12 | $8 – $20 | 50+ Years | Very Good. Highly resistant to rot, pests, fire, and moisture. Holds paint well. Can be prone to chipping or cracking upon sharp impact. | High. Very heavy and brittle. Requires special cutting tools (diamond blades) and careful handling. Installation is labor-intensive and typically requires a larger crew. |
| Brick Veneer | $6 – $15 | $20 – $50+ | 100+ Years | Excellent. Impervious to rot, pests, and fire. Provides excellent thermal mass and sound insulation. Mortar joints may require re-pointing after several decades. | Very High. Labor-intensive and requires highly skilled masons for proper installation, including foundations, wall ties, and mortar work. Slowest installation process. |
| Steel Cladding | $6 – $16 | $12 – $30 | 40 – 70 Years | Good to Very Good. Very strong and impact-resistant. However, if the protective coating is scratched, it is susceptible to rust. Heavier than aluminum. | Medium to High. Heavier than aluminum, requiring more robust framing and handling. Installation is similar to aluminum but requires more effort due to weight. |
Advantage
Aluminium cladding offers numerous benefits in terms of design flexibility. With this material, you’ve the opportunity to create a unique and eye-catching look for your building. The finishes available include brushed, polished, anodized, and powder-coated, allowing you to achieve the desired aesthetic effect.
Advantage
Aluminium cladding offers numerous benefits in terms of design flexibility. With this material, you’ve the opportunity to create a unique and eye-catching look for your building. The finishes available include brushed, polished, anodized, and powder-coated, allowing you to achieve the desired aesthetic effect.
Advantage
Aluminium cladding offers numerous benefits in terms of design flexibility. With this material, you’ve the opportunity to create a unique and eye-catching look for your building. The finishes available include brushed, polished, anodized, and powder-coated, allowing you to achieve the desired aesthetic effect.
Xtrametal is here with more than 50+ large-scale public building facade system design and project evaluation experience. Metal cladding walls, aluminum louver facades, aluminum exterior wall decorative panels, 3D facade decorative panels, etc., can all be modularly installed and are widely used in exterior wall construction projects such as supermarkets, airports, hotels, stations, apartments, etc.
Our dedicated team is ready to assist with technical specifications, samples, and project consultations.
An extensive palette of colors, unique finishes like wood-grain and metallic, and custom shaping capabilities.
Our products meet rigorous building codes and fire-safety standards for your peace of mind.
Resistant to corrosion, UV rays, and extreme weather, ensuring a long-lasting, pristine facade.
Please send us a detailed inquiry and drawing. Include specifics such as size, layout, dimensions, color, material, and finish that you want for your project.
We will quote for you within 24 hours ! We have 400+ sale teams in designing and manufacturing for you .
After sending us your design and specifics, our sales team and engineers will offer 2-3 product solutions depending on your design and budget, subject to final approval.
As soon as you approves, a contract shall be signed. From here, the customization and manufacturing process begin.And our sales people would send you pictures of the production process and the finished product.
When your order completed and was packed, we would organize to load containers and shipping to your port .Even delivery to your warehouse.
XtraMetal has been in building product manufacturing for 32 years and we have encountered all kinds of problems, here are the most important concerns of our customers before closing the deal.
PVDF fluorocarbon coating is mandatory for exterior applications. 70% PVDF resin content guarantees 25 – year color retention (ASTM D2244). Powder coating lasts 10 – 15 years; anodizing shows color limitations. Specify 30 – 40μm coating thickness with UV – resistant primers.
Implement these manufacturing controls:
1. Material: Use 3003 – H24/H44 alloy (0.2% yield strength ≥145MPa).
2. Stiffening: CNC – folded edge ribs (≥25mm height) every 600mm.
3. Tolerance: Limit flatness deviation to ≤2mm/m (EN 485 – 3 standard).
Hexagonal perforations with 20 – 30% open area provide optimal NRC 0.75 – 0.85.
Microperf (Φ2 – 3mm): 8% open area for visual screening.
Linear Slots: 15% open area for directional airflow. Verify with ISO 354 reverberation chamber tests.
We enforce the GB/T 9286 color difference control standard, ensuring ΔE≤1.5 (visually no color difference). We offer a triple
confirmation mechanism using Pantone color cards, RAL color systems, and physical samples, supporting sample retention.
Minimum order quantity is 20㎡ (special processes start at 50㎡), with regular orders delivered within 15 working days. Complex
process orders do not exceed 25 working days (including a 7-day curing period).
